Polyamide Machine Tapes
The traction layer of Polyamide Machine Tapes is highly resilient and can cope with intermittent overloads, which prevents residual elongation. This makes re tensioning unnecessary, and avoids costly and time-consuming machine downtimes.

Main features:
  • Good dimensional stability
  • Can cope with intermittent overloads, very forgiving
  • Very good reversed bending and flex fatigue properties
  • High abrasion resistance
  • Application-oriented surface properties, gentle treatment of transported goods
    • .
    Warranties Polyamide Machine Tapes / Belts
    Call Stiles For Vacuum Cups
      Thick Pulley Dia. (min.) Tensile force for 1% elongation (K1% Static) Per Width Unit Conveying Side (3) Traction layer (2) Running Side/Pulley Side (1)
    Code Click Pic For Detail  mm  mm N/mm Material Surface Property Color Material Material Surface Property Color
    A-1 A-1 1.2 40   Acrylonitrile-Butadiene-Rubber (NBR) Matt Adhesive Green PA Polyurethane cross-linked (PUR) Smooth Non-adhesive Black
    F-0 F-0 0.7 20 5.5 Acrylonitrile-Butadiene-Rubber (NBR) Rough structure Adhesive Green PA Acrylonitrile-Butadiene-Rubber (NBR) Impreg. fabric Non-adhesive Green
    F-1 F-1 1.25 40 8.5 Acrylonitrile-Butadiene-Rubber (NBR) Rough structure Adhesive Green PA Acrylonitrile-Butadiene-Rubber (NBR) Impreg. fabric Non-adhesive Green


    For Additional Information And Delivery Information Call Our Office


    .
